Configure multiple IP Address with single default port 1521
Posted by Mir Sayeed Hassan on March 10th, 2018
Configure multiple IP Address with single default port 1521
sys@TESTDB> select INSTANCE_NAME,VERSION,STATUS from v$instance; INSTANCE_NAME VERSION STATUS ---------------- ----------------- ------------ testdb 11.2.0.4.0 OPEN
Configure the listener
[oracle@testdb admin]$ cat listener.ora LISTENER = (DESCRIPTION_LIST = (DESCRIPTION = (ADDRESS = (PROTOCOL = TCP)(HOST = 192.168.120.123)(PORT = 1521)) (ADDRESS = (PROTOCOL = TCP)(HOST = 192.168.120.83)(PORT = 1521)) (ADDRESS = (PROTOCOL = IPC)(KEY = EXTPROC1521)) ) ) ADR_BASE_LISTENER = /u01/app/oracle
Configure the tnsnames
[oracle@testdb admin]$ cat tnsnames.ora TESTDB = (DESCRIPTION = (ADDRESS_LIST = (ADDRESS = (PROTOCOL = TCP)(HOST = 192.168.120.123)(PORT = 1521)) ) (CONNECT_DATA = (SERVICE_NAME = testdb) ) ) TESTDB = (DESCRIPTION = (ADDRESS_LIST = (ADDRESS = (PROTOCOL = TCP)(HOST = 192.168.120.83)(PORT = 1521)) ) (CONNECT_DATA = (SERVICE_NAME = testdb) ) )
Stop the listener
[oracle@testdb admin]$ lsnrctl stop LSNRCTL for Linux: Version 11.2.0.4.0 - Production on 10-MAR-2018 16:24:27 Copyright (c)1991, 2013, Oracle. All rights reserved. Connecting to (DESCRIPTION=(ADDRESS=(PROTOCOL=TCP)(HOST=192.168.120.123)(PORT=1521))) The command completed successfully
[oracle@testdb admin]$ lsnrctl start LSNRCTL for Linux: Version 11.2.0.4.0 - Production on 10-MAR-2018 16:24:42 Copyright (c) 1991, 2013, Oracle. All rights reserved. Starting /u01/app/oracle/product/11.2.0/dbhome_1/bin/tnslsnr: please wait... TNSLSNR for Linux: Version 11.2.0.4.0 - Production System parameter file is /u01/app/oracle/product/11.2.0/dbhome_1/network/admin/listener.ora Log messages written to /u01/app/oracle/diag/tnslsnr/testdb/listener/alert/log.xml Listening on: (DESCRIPTION=(ADDRESS=(PROTOCOL=tcp)(HOST=192.168.120.123)(PORT=1521))) Listening on: (DESCRIPTION=(ADDRESS=(PROTOCOL=tcp)(HOST=192.168.120.83)(PORT=1521))) Listening on: (DESCRIPTION=(ADDRESS=(PROTOCOL=ipc)(KEY=EXTPROC1521))) Connecting to (DESCRIPTION=(ADDRESS=(PROTOCOL=TCP)(HOST=192.168.120.123)(PORT=1521))) STATUS of the LISTENER ------------------------ Alias LISTENER Version TNSLSNR for Linux: Version 11.2.0.4.0 - Production Start Date 10-MAR-2018 16:24:42 Uptime 0 days 0 hr. 0 min. 0 sec Trace Level off Security ON: Local OS Authentication SNMP OFF Listener Parameter File /u01/app/oracle/product/11.2.0/dbhome_1/network/admin/listener.ora Listener Log File /u01/app/oracle/diag/tnslsnr/testdb/listener/alert/log.xml Listening Endpoints Summary... (DESCRIPTION=(ADDRESS=(PROTOCOL=tcp)(HOST=192.168.120.123)(PORT=1521))) (DESCRIPTION=(ADDRESS=(PROTOCOL=tcp)(HOST=192.168.120.83)(PORT=1521))) (DESCRIPTION=(ADDRESS=(PROTOCOL=ipc)(KEY=EXTPROC1521))) The listener supports no services The command completed successfully
Wait for some time, the listener will start automatically as shown below
[oracle@testdb admin]$ lsnrctl status LSNRCTL for Linux: Version 11.2.0.4.0 - Production on 10-MAR-2018 16:38:03 Copyright (c) 1991, 2013, Oracle. All rights reserved. Connecting to (DESCRIPTION=(ADDRESS=(PROTOCOL=TCP)(HOST=192.168.120.123)(PORT=1521))) STATUS of the LISTENER ------------------------ Alias LISTENER Version TNSLSNR for Linux: Version 11.2.0.4.0 - Production Start Date 10-MAR-2018 16:36:45 Uptime 0 days 0 hr. 1 min. 17 sec Trace Level off Security ON: Local OS Authentication SNMP OFF Listener Parameter File /u01/app/oracle/product/11.2.0/dbhome_1/network/admin/listener.ora Listener Log File /u01/app/oracle/diag/tnslsnr/testdb/listener/alert/log.xml Listening Endpoints Summary... (DESCRIPTION=(ADDRESS=(PROTOCOL=tcp)(HOST=192.168.120.123)(PORT=1521))) (DESCRIPTION=(ADDRESS=(PROTOCOL=tcp)(HOST=192.168.120.83)(PORT=1521))) (DESCRIPTION=(ADDRESS=(PROTOCOL=ipc)(KEY=EXTPROC1521))) (DESCRIPTION=(ADDRESS=(PROTOCOL=tcp)(HOST=testdb)(PORT=8087))(Presentation=HTTP)(Session=RAW)) Services Summary... Service "primXDB" has 1 instance(s). Instance "testdb", status READY, has 1 handler(s) for this service... Service "testdb" has 1 instance(s). Instance "testdb", status READY, has 1 handler(s) for this service... The command completed successfully
Check the tnsping with 2 different IP
[oracle@testdb admin]$ tnsping 192.168.120.123 TNS Ping Utility for Linux: Version 11.2.0.4.0 - Production on 10-MAR-2018 16:26:20 Copyright (c) 1997, 2013, Oracle. All rights reserved. Used parameter files: /u01/app/oracle/product/11.2.0/dbhome_1/network/admin/sqlnet.ora Used EZCONNECT adapter to resolve the alias Attempting to contact (DESCRIPTION=(CONNECT_DATA=(SERVICE_NAME=))(ADDRESS=(PROTOCOL=TCP)(HOST=192.168.120.123)(PORT=1521))) OK (0 msec)
[oracle@testdb admin]$ tnsping 192.168.120.83 TNS Ping Utility for Linux: Version 11.2.0.4.0 - Production on 10-MAR-2018 16:26:31 Copyright (c) 1997, 2013, Oracle. All rights reserved. Used parameter files: /u01/app/oracle/product/11.2.0/dbhome_1/network/admin/sqlnet.ora Used EZCONNECT adapter to resolve the alias Attempting to contact (DESCRIPTION=(CONNECT_DATA=(SERVICE_NAME=))(ADDRESS=(PROTOCOL=TCP)(HOST=192.168.120.83)(PORT=1521))) OK (0 msec)
====Hence tested & verified in our test env====
